12V-24V Anti UV Infrared Photocell Sensor For Boom Barrier FCC approved

12V-24V Anti UV Infrared Photocell Sensor For Boom Barrier FCC approved

Brand Name: JUTAI
Model Number: IR-20
MOQ: Support 1-10 Pcs for Sample
Price: Negotiation
Packaging Details: 50 Pcs 1 Carton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal, Alipay
Detail Information
Place of Origin:
China
Certification:
CE, FCC
Document:
Name:
Infrared Photocell Sensor
Operation Temp:
-10 ℃ ~ +60 °C
Detection Mode:
Presence Detect
Power Supply:
12/24 V AC/DC
Rx Working Current:
35mA
Material:
ABS+PC Anti-UV Material
Detection Distance:
20 M
HS Code:
8531901000
Tx Working Current:
25mA
Relay Contact:
Max 500mA E 48VAC/DC
IP Rating:
IP 65
Product Size:
45*33*90 Mm
Package Size:
115*115*40 Mm
Net Weight:
124 G
Gross Weight:
166 G
Supply Ability:
5000 Pcs per Month
Highlight:

24V Infrared Photocell Sensor

,

Anti UV Infrared Photocell Sensor

,

Boom Barrier Infrared Photocell Sensor

Product Description

Infrared Photocell Sensor for Boom Barrier Safety Waterproof Design 12-24 V Anti-UV Material

    The Infrared Photocell Sensor for Boom Barrier Safety is a cutting-edge solution designed to ensure secure and efficient operation of boom barriers. This sensor utilizes advanced infrared technology to detect the presence of vehicles and pedestrians, enhancing safety at access points. With its reliable functionality, it prevents accidents by ensuring that barriers only operate when it is safe to do so, making it an essential component for parking lots, toll booths, and secure facilities.

    One of the key features of this infrared photocell sensor is its waterproof design, which allows for dependable performance in various weather conditions. Rated for outdoor use, it effectively resists moisture, protecting the internal components and ensuring long-lasting functionality. This durability is complemented by the use of anti-UV materials, which safeguard the sensor from harmful sun exposure, preventing degradation and maintaining optimal performance over time. This makes it particularly suitable for environments with direct sunlight.

    Operating on a versatile voltage range of 12-24 V, this sensor is compatible with various boom barrier systems, facilitating easy integration into existing setups. Its user-friendly design ensures straightforward installation, minimizing downtime and allowing for quick deployment. The Infrared Photocell Sensor not only enhances safety but also contributes to the overall efficiency of traffic management systems. With its combination of waterproof construction, UV resistance, and flexible voltage compatibility, this sensor is a reliable choice for enhancing boom barrier safety in diverse applications.

                                            Infrared Photocell






Feature



  • Anti-Strong Light Interference:

    • Resistant to strong light interference, ensuring reliable performance even in environments with bright lighting.
  • High Temperature Resistance:

    • Built to withstand high temperatures, maintaining functionality in hot climates and harsh conditions.
  • Active Infrared Technology:

    • Utilizes active infrared technology for reliable and precise human presence detection.
  • 20m Detection Range:

    • Capable of detecting human presence up to 20 meters, providing extensive coverage.
  • Waterproof Design:

    • Designed for outdoor use with a durable, waterproof construction ensuring longevity and functionality in various weather conditions.
  • Infrared Beam Sensor:

    • Equipped with an infrared beam sensor that enhances accuracy and minimizes false alarms.
  • Versatile Application:

    • Suitable for a wide range of applications including gate openers, automatic doors, sliding gates, swing gates, security doors, and other security systems.
  • Easy Installation:

    • Simple installation process with clear instructions, making it user-friendly and convenient to set up.
  • Adjustable Trigger Response Time:

    • Features an adjustable trigger response time to prevent unnecessary interference and reduce false alarms.
  • Enhanced Security and Safety:

    • Provides an added layer of security and safety for properties by reliably detecting human presence and potential intrusions.
  • Red LED Indicator:

    • Includes a red LED indicator for easy monitoring and status verification.



                                               Infrared Sensor






Application



  • Gate Openers:

    • Ensures safe and efficient operation of sliding and swing gates by detecting human presence and preventing accidental closure or opening.
  • Automatic Doors:

    • Provides enhanced security and convenience for automatic doors in commercial buildings, shopping malls, hospitals, and other high-traffic areas.
  • Security Doors:

    • Enhances the security of entrance doors by detecting unauthorized access attempts and integrating with alarm systems to alert security personnel.
  • Garage Doors:

    • Ensures the safety of residents and vehicles by preventing garage doors from closing when an object or person is detected in the path.
  • Parking Systems:

    • Improves the functionality of parking management systems by detecting vehicles and pedestrians, thus preventing accidents and optimizing traffic flow.
  • Anti-Theft Alarm Systems:

    • Integrates with anti-theft systems to provide an additional layer of security by detecting intrusions and triggering alarms to deter unauthorized access.
  • Outdoor Security:

    • Suitable for outdoor security applications in residential and commercial properties, including gardens, driveways, and perimeters, providing reliable detection in various weather conditions.
  • Access Control Systems:

    • Enhances access control systems by ensuring that only authorized personnel can enter restricted areas, thereby improving overall security management.
  • Industrial Automation:

    • Ideal for use in industrial settings where automated processes require precise human detection to ensure safety and efficiency.
  • Public Facilities:

    • Applicable in public facilities such as schools, airports, and train stations, ensuring the safety and security of large numbers of people by detecting unauthorized access and preventing accidents.

                                           infrared sensor12V-24V Anti UV Infrared Photocell Sensor For Boom Barrier FCC approved 3






Series

Model  Detection Range Connection Way
IR-20 20 M Wire
IPS-20 R 20 M Wire
IS-30 R 30 M Wireless
WIS-30 30 M Wire
BP-20 20 M  Wireless
