Barrier Radar Detector
>
24.150GHz Barrier Radar Sensor IP67 Car Detect Only Easy install

24.150GHz Barrier Radar Sensor IP67 Car Detect Only Easy install

Brand Name: JUTAI
Model Number: RD24-6M
MOQ: Support 1-10 Pcs for Sample
Price: Negotiation
Packaging Details: 50 Pcs 1 Carton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal, Alipay
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, FCC
Document:
Name:
Barrier Radar Sensor
Housing Material:
ABS+PC
Input Voltage:
10-24 VDC
Relay Control Time:
1-6s Adjustable
IP Rate:
IP 67
Operating Frequency:
24.150GHz
Detection Range:
1-6m
Operation Temp:
-40ºC~+70ºC
Relay Contact:
1 A @24 V DC/AC
Response Time:
20-90 Ms
Horizontal Detection Angle:
0-28 °
Vertical Detection Angle:
0-60 °
Product Size:
98*20.5*118 Mm
Package Size:
143*106*55 Mm
Net Weight:
150 G
Gross Weight:
200 G
HS Code:
8526101090
Supply Ability:
5000 Pcs per Month
Highlight:

24.150GHz Barrier Radar Sensor

,

Barrier Radar Sensor IP67

,

Car Detect Barrier Radar Sensor

Product Description

24.150 Ghz Barrier Radar Sensor Waterproof Rapid Response Car Detect Only IP 67



    The 24.150 GHz Barrier Radar Sensor is an advanced detection solution specifically engineered for vehicle monitoring at barrier systems. Utilizing cutting-edge radar technology, this sensor ensures precise and reliable detection of cars, enhancing safety and efficiency at access points such as parking facilities and toll booths. Designed for optimal performance, it excels in accurately identifying vehicle presence, allowing for seamless operation of boom barriers while minimizing the risk of accidents.

    A standout feature of this radar sensor is its rapid response capability. Engineered for immediate activation, it allows barriers to react almost instantly to the approach of vehicles, significantly reducing wait times and enhancing the flow of traffic. This quick response is particularly advantageous in busy environments, where maintaining efficient access is crucial. The sensor is dedicated solely to car detection, reducing the likelihood of false triggers from pedestrians or other objects, thereby increasing the reliability of the barrier system.

    Built to endure harsh environmental conditions, the 24.150 GHz Barrier Radar Sensor boasts an IP 67 rating, ensuring complete protection against dust and immersion in water. This robust design guarantees dependable performance in various weather scenarios, making it ideal for outdoor installations. Additionally, the user-friendly design allows for easy installation and integration with existing barrier systems, facilitating quick deployment. With its combination of advanced radar technology, rapid response features, and superior waterproof capabilities, this barrier radar sensor is an essential component for enhancing vehicle safety and operational efficiency in diverse applications.

                                                     Barrier sensor




Key Feature



  • 1. Adjustable detection distance from 1-6 m
    • The RD24-6 can be operated by setting the detection distance via a pushbutton that comes with the radar, in combination with the three indicator lights on the radar. We can set the detection distance of the radar according to the length of the barrier arm.
  • 2. Pedestrian and vehicle distinction
    • RD24-6M radar detector in the range of 1-6m can achieve the function of only detecting vehicles, but also vehicles and pedestrians can be detected, two modes for your choice. So that the radar can adapt to different scenes.
  • 3. Strong environmental adaptability
    • The radar system is not affected by rain, snow, dust and other inclement weather, which ensures all-weather stable operation.
  • 4. Easy installation
    • No need to dig trench or bury coil on the ground, the installation process is faster and easier, reducing the construction difficulty and cost.
  • 5. High-precision detection
    • Advanced radar technology can provide high-precision object detection and distance measurement, ensuring the accuracy of the gate operation.
  • 6. Durability and Stability
    • Radar systems usually have high durability and stability, reducing maintenance needs and costs.
  • 7. Strong anti-interference capability
    • Radar systems are more resistant to interference than ground sensing coils and can maintain good performance in complex environments.

                                                    Barrier Radar




Application


  • 1. Car park management:
    • Entry and exit vehicle identification and control to prevent unauthorised vehicle entry.
  • 2. Commercial and office buildings:
    • Provide safe and reliable vehicle access management to ensure building security.
    • Automated operation, reducing manual intervention and improving work efficiency.
  • 3. Industrial Parks:
    • Accurate detection and management of heavy vehicles to improve logistics efficiency.
    • Real-time monitoring to improve security and management in the park.
  • 4. Residential neighbourhoods:
    • Automatic identification of residents and visitor vehicles to improve community security.
    • Convenient management of visitor vehicles to provide a better service experience.
  • 5. Transport hubs:
    • Used for vehicle entry and exit management in railway stations, airports, bus stations and other places.
    • Improve the operational efficiency and safety of transport hubs.


                                             barrier radar detector




Certification

                                                   barrier radar certification


Specification

Technology Microwave Doppler Rada
Operating Frequency 24.150 GHZ
Input Voltage 10-24 VDC ±10%
Detection Mode Motion
Working Current <150 MA
Output Power (EIRP) <20 DBM
Relay Pulse Mode 1-6s (Adjustable)
Detection Angle (Horizontal) 0-28°
Detection Angle (Vertical) 0-60°
Detection Range 1-6M (3.3-19.7FT)
Dimensions 118*98*26mm 0.39*0.32*0.09 FT
Operation Temperature -40℃ ~ +70℃
Detectable Speed 20-90 ms
Housing Materials ABS
Relay Control Time 1-6s Adjustable
Degree of Protection IP65
