Barrier Radar Detector
>
Easy Setting Rapid Response Vehicle Detection Sensor 1-6 M Detection Range

Easy Setting Rapid Response Vehicle Detection Sensor 1-6 M Detection Range

Brand Name: JUTAI
Model Number: RD24-6M
MOQ: Support 1-10 Pcs for Sample
Price: Negotiation
Packaging Details: 50 Pcs 1 Carton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal, Alipay
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, FCC
Document:
Name:
Vehicle Detection Sensor
Operating Frequency:
24.150GHz
Vertical Detection Angle:
0-60 °
Housing Material:
ABS+PC
Horizontal Detection Angle:
0-28 °
Operation Temp:
-40ºC~+70ºC
Input Voltage:
10-24 VDC
Relay Control Time:
1-6s Adjustable
IP Rate:
IP 67
Detection Range:
1-6m
Relay Contact:
1 A @24 V DC/AC
Response Time:
20-90 Ms
Product Size:
98*20.5*118 Mm
Package Size:
143*106*55 Mm
Net Weight:
150 G
Gross Weight:
200 G
HS Code:
8526101090
Supply Ability:
5000 Pcs per Month
Highlight:

Easy Setting Vehicle Detection Sensor

,

Rapid Response Vehicle Detection Sensor

,

Vehicle Detection Sensor

Product Description

Vehicle Barrier Sensor 1-6 m Detection Range Waterproof Boom Gate Sensor Rapid Response Easy Setting

    The Vehicle Barrier Sensor is a highly effective solution designed to enhance safety and efficiency at boom gates. With a detection range of 1-6 meters, this sensor accurately detects vehicles, ensuring reliable operation in various environments, including parking lots and entry points.

    Featuring rapid response technology, the sensor quickly activates the barrier upon detecting a vehicle, facilitating smooth and timely access for drivers. Its waterproof design ensures dependable performance in all weather conditions, making it ideal for outdoor installations.

    The Vehicle Barrier Sensor is also designed for easy setting adjustments, allowing users to customize detection parameters to meet specific operational requirements. By integrating this advanced sensor into vehicle monitoring systems, businesses can significantly improve safety measures, streamline traffic management, and create a secure environment that prioritizes the well-being of both vehicles and pedestrians.



           Barrier sensor




Key Feature



  • 1. Adjustable detection distance from 1-6 m
    • The RD24-6 can be operated by setting the detection distance via a pushbutton that comes with the radar, in combination with the three indicator lights on the radar. We can set the detection distance of the radar according to the length of the barrier arm.
  • 2. Pedestrian and vehicle distinction
    • RD24-6M radar detector in the range of 1-6m can achieve the function of only detecting vehicles, but also vehicles and pedestrians can be detected, two modes for your choice. So that the radar can adapt to different scenes.
  • 3. Strong environmental adaptability
    • The radar system is not affected by rain, snow, dust and other inclement weather, which ensures all-weather stable operation.
  • 4. Easy installation
    • No need to dig trench or bury coil on the ground, the installation process is faster and easier, reducing the construction difficulty and cost.
  • 5. High-precision detection
    • Advanced radar technology can provide high-precision object detection and distance measurement, ensuring the accuracy of the gate operation.
  • 6. Durability and Stability
    • Radar systems usually have high durability and stability, reducing maintenance needs and costs.
  • 7. Strong anti-interference capability
    • Radar systems are more resistant to interference than ground sensing coils and can maintain good performance in complex environments.

                                                    Barrier Radar




Application


  • 1. Car park management:
    • Entry and exit vehicle identification and control to prevent unauthorised vehicle entry.
  • 2. Commercial and office buildings:
    • Provide safe and reliable vehicle access management to ensure building security.
    • Automated operation, reducing manual intervention and improving work efficiency.
  • 3. Industrial Parks:
    • Accurate detection and management of heavy vehicles to improve logistics efficiency.
    • Real-time monitoring to improve security and management in the park.
  • 4. Residential neighbourhoods:
    • Automatic identification of residents and visitor vehicles to improve community security.
    • Convenient management of visitor vehicles to provide a better service experience.
  • 5. Transport hubs:
    • Used for vehicle entry and exit management in railway stations, airports, bus stations and other places.
    • Improve the operational efficiency and safety of transport hubs.


                                             barrier radar detector




Certification

                                                   barrier radar certification


Company Profile
JUTAI, a premier manufacturer of Motion Sensor and Photoelectric Sensors, excels in R&D, production, sales, and distribution. Our dedication to innovation and quality drives us to offer superior solutions to our customers. We aim to be your reliable production partner, helping build and enhance your unique brand identity.
