Low Frequency Reader 125K
>
Auto Tuning 125KHZ RFID Reader Module 130cm Reading Range For Visitor Management

Auto Tuning 125KHZ RFID Reader Module 130cm Reading Range For Visitor Management

Brand Name: JUTAI
Model Number: GP99
MOQ: Support 1-10 Set for Sample
Price: Negotiation
Packaging Details: 1 Pcs 1 Carton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal, Alipay
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, FCC
Document:
Name:
125KHZ RFID Reader Module
Audio / Visua Indication:
Bright Blue LED And Buzzer
Interfaces:
Wiegand 26 Or 34 Bits, RS232 Or RS485
Power Supply Input Voltage:
AC 120V / 60Hz Or 230V/50Hz
Housing Material:
ABS+PC, UV Protection
RFID Cards Accepted:
125kHz, 64 Bits, Manchester Encoding
Output Voltage:
DC 12V / 1A
IP Level:
IP 65
Reading Range:
130 Cm
Product Size:
420*320*47 Mm
Package Size:
52*48*13 CM
Net Weight:
1934 G
Gross Weight:
5 Kg
Working Current:
≤450mA
Relative Humidity:
≤90%
Baud Rate:
9600, N, 8, 1
Card Type:
125 K More Copper Wire Type
Color:
Black
HS Code:
847160900
Supply Ability:
5000 Pcs per Month
Highlight:

Auto Tuning 125KHZ RFID Reader

,

125KHZ RFID Reader Module

,

Visitor Management 125KHZ RFID Reader

Product Description

125K Reader for Visitor Management Auto-Tuning Function and 130 cm Reading Range

    The 125K Reader for Visitor Management is a state-of-the-art solution designed to streamline access control and enhance security in various environments. Featuring an impressive reading range of up to 130 cm, this reader allows for efficient scanning of RFID tags, ensuring quick and seamless entry for visitors. Its advanced auto-tuning function optimizes performance by automatically adjusting to the environment, minimizing interference and improving reading accuracy.

    Ideal for high-traffic areas such as corporate offices, event venues, and secure facilities, the 125K Reader enhances visitor management processes by facilitating fast and reliable access. The user-friendly design ensures straightforward installation and integration with existing visitor management systems. Equipped with robust technology, this reader provides peace of mind by ensuring secure and efficient access control. Experience the benefits of enhanced security and convenience with the 125K Reader, making visitor management more effective and streamlined.



                                        access control reader






Features

  • 1. Solar Film Penetration (V-Kool40)
    • Capable of reading RFID cards inside vehicles with solar film applied, eliminating the need to roll down windows.
  • 2. Auto-Tuning Function
    • Adjusts automatically to compensate for metal and interference, ensuring stable performance in various environments.
  • 3. Extended Reading Range
    • Reading distance ranges from 90 cm to 130 cm, depending on on-site interference.
  • 4. Bright LED Indicators
    • Equipped with LED display bars and a buzzer for clear reading status indications.
  • 5. Firmware Upgradable
    • Allows field updates to the device’s firmware to maintain optimal performance.
  • 6. IP-65 Waterproof Housing
    • Provides protection against water ingress, ensuring reliable operation in rainy conditions without additional accessories.
  • 7. High-Quality Power Supply
    • Includes noise filtering to provide stable current and reduce external interference.
  • 8. Loop Detection Function (Optional):
    • Can be integrated with vehicle loop detectors to enhance system reliability and stability.
  • Anti-Rereading Function
    • Prevents the same card from being read multiple times within a short period, addressing interference issues between readers.

                                       rfid reader






Wiring



Color Funtion

Red

12V(Connect to power supply)

Black

GND(Connect to power supply)

White-Green

Wiegand D0

Yellow

Wiegand D1

Blue

RS232-RXD

Gray

RS232-TXD

White-red

Read ID interval-A

Orange

Read ID interval-B

White

RS485-A

Brown

RS485-B

Purple

Reserve

Dark blue

Loop Detector(Connect to GND)

Red

Relay COM

White-Black

Relay N.O

Pink

Relay N.C

Black

GND




Applications

  • Access Control
    • Used in commercial buildings and residential areas to manage and secure entry and exit points.
  • Parking Systems
    • Manages vehicle entry and exit at parking facilities, providing convenient access control.
  • Through-Wall Reading Applications
    • Reads cards without direct contact, suitable for specific environments.
  • Personal Identification
    • Ideal for scenarios requiring long-distance identity verification, such as large conferences or events.
  • Any Long-Range Reading Application
    • Suitable for various long-distance reading needs, such as warehouse management.
  • Hand-Free Applications
    • Enables convenient access without physically handling the card, enhancing user experience.



                                         Rfid reader
