79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates

Brand Name: JUTAI
Model Number: RD79-6M
MOQ: Support 1-10 Sample Order
Price: Negotiation
Packaging Details: Cartoon
Payment Terms: Western Union,T/T,Paypal,Alipay,Alibaba link
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE
Document:
79G radar.pdf
Model:
RD79-6M
Working Frequenc RD79-6M Y:
79～81GHz
Detection Zone Length:
1-6m
Detection Zone Width:
0.5–1.5 Meters To The Right And 0.5–1.5 Meters To The Left Of The Central Line
Interface:
4G（optional）、Bluetooth 5.0、 RS485
Response Time:
≤ 100ms
Supply Voltage:
DC12~24V
Maximum Operating Current:
600mA
Average Power:
1.2W（@12V）
Size:
110.9*73.9*17.5mm
Protection Level:
IP66
Working Temperature:
-40°C ~ ﹢80°C
Supply Ability:
2000 pcs per month
Highlight:

79-81GHz Barrier Radar Detector

,

IP66 Protection Barrier Radar Detector

,

Adjustable Detection Zone Automatic Barrier Gate Sensor

Product Description
Automatic Barrier Gate Radar Detector
Advanced millimeter wave radar with horizontal 0.2-6m and vertical 3m adjustable detection range for precise automated passage control.
Product Overview
The RD79-6M Automatic Barrier Gate Radar Detector delivers exceptional precision in object detection with a customizable sensing area adjustable from 0.2 to 6 meters horizontally and up to 3 meters vertically. This high-precision system provides 0.1m accuracy, ensuring optimal fit for any traffic lane configuration. Through the dedicated "GL Control" App, users can fine-tune parameters via Bluetooth to establish exact boundaries that prevent false triggers while maintaining rapid 100ms response times.
This versatile radar detector supports both Trigger Mode and Safety Anti-Pinch Mode, utilizing advanced 79GHz to 81GHz mmWave technology for operational stability unaffected by environmental conditions. With IP66-rated protection and RS485 interface, the RD79-6M integrates seamlessly into barrier gate systems to provide reliable, all-weather vehicle detection and pedestrian safety. Its intelligent target filtering distinguishes between human and vehicle targets, making it essential for sophisticated traffic management.
79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 0
Product Specifications
79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 1
Key Features
  • High-precision 79GHz millimeter wave technology with strong environmental adaptability, unaffected by rain, snow, dust, or strong light
  • Pedestrian filtering function (Vehicle Detect Only) accurately identifies and ignores pedestrians, eliminating need for traditional ground sense coils
  • Direction recognition function prevents vehicles from "reversing" into exits for enhanced safety
  • Mobile app parameter adjustment via "GL Control" APP with intuitive operation
  • IP66 protection rating for industrial-grade waterproof and dustproof performance in harsh outdoor environments
  • Rapid response time ≤ 100ms with low power consumption of 1.2W (12V)
  • Detection range: 1-6m length, 0.5-1.5m width per side, supporting dual target detection of people and vehicles
79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 2
Key Advantages of 79GHz Barrier Radar Technology
High Precision and Fine-Grained Detection
Operating at 79GHz provides wider bandwidth for superior range and velocity resolution. Capable of distinguishing between small objects like pedestrians, bicycles, and motorcycles that traditional loops often miss. Creates precise "virtual curtain" detection that eliminates dead zones and prevents barrier drops when objects are present.
Directional Discrimination
Advanced motion direction sensing prevents false triggers by ignoring traffic moving away from the gate or walking parallel. Enables strict one-way access control by only responding to approaching targets, enhancing security in restricted areas.
Non-Intrusive Installation
Surface-mounted technology eliminates need for road cutting and wire burial, preserving pavement integrity and significantly reducing labor costs. Rapid deployment and maintenance without extended lane closures.
All-Weather Reliability
79GHz millimeter-wave technology operates reliably in darkness, direct sunlight, heavy rain, snow, and fog where optical sensors often fail. Protected casing on the barrier prevents mechanical wear from vehicle traffic.
Intelligent Human-Vehicle Differentiation
Sophisticated algorithms categorize objects using micro-doppler signatures. Maintains safety by detecting pedestrians following vehicles into detection zones. Digitally configurable detection length and width via software or mobile apps.
Technical Specifications Summary
Feature 79GHz Radar Advantage
Safety High-density detection of both humans and vehicles
Efficiency Faster response times and direction-based logic
Maintenance Minimal; no road repairs or wire replacements needed
Adaptability Works in all weather conditions and complex terrains
Mobile App Configuration
Parameter setting and calibration through "GL Control" mobile application:
Android: Scan QR code below
iOS: Search for "GL Control" in the App Store
79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 3 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 4 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 5 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 6 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 7 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 8 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 9 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 10
Packaging
79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 11 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 12 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 13 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 14 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 15 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 16 79-81GHz Barrier Radar Detector with IP66 Protection and Adjustable Detection Zone for Automatic Barrier Gates 17
