• High-Efficiency DC Brushless Motor

  The A9 barrier gate uses a DC brushless motor for efficient and stable operation. It helps reduce power consumption, lowers mechanical wear and supports long-term reliable performance.

• Dual-Spring Balance Design

  The dual-spring structure helps balance the boom arm load, reducing stress on the motor and transmission system. This design improves operation stability and extends service life.

• Multiple Opening Speed Options

  The A9 supports 1.5s, 3s and 6s open/close speed options, allowing customers to choose the right model according to traffic flow, boom length and site requirements.

• Fast-Start and Slow-Stop Operation

  The motor supports fast-start and slow-stop technology. This makes the boom arm movement smoother, reduces impact at the end position and improves user experience.

• Auto-Lock Function

  The barrier gate can be locked at any angle between 0° and 90°, improving operational safety and stability during use.

• Easy Installation and Maintenance

  The simplified mechanical design allows easier installation, adjustment and maintenance. This is especially useful for installers, parking system integrators and maintenance teams.

• Multiple Boom Arm Options

  The A9 supports straight boom, telescopic boom, 90° folding boom, 180° folding boom, fence boom and LED strip boom options. It can adapt to standard parking lots, underground parking, low-ceiling entrances and special vehicle access layouts.

• Safety Input and Output Support

  The system supports input signals such as gate open, gate close, stop, ground sense and anti-crush. It also provides dry contact outputs for fully opened and fully closed status.

• RS232 / RS485 Communication

  With RS232 and RS485 communication interfaces, the A9 can be integrated into parking management systems, access control platforms and smart entrance control solutions.

• Wide Operating Temperature Range

  The A9 can operate from -35°C to 75°C, making it suitable for hot, cold and demanding outdoor environments.

• Backup Battery & Super Capacitor Support

  The barrier gate supports an external 24V 1Ah backup battery, which can provide up to 200 operating cycles during power failure, helping maintain normal vehicle access when the main power supply is interrupted.

  It can also be equipped with a super capacitor option, allowing the barrier arm to open 1–2 times after power outage for emergency access or manual site recovery.

The JUTAI A9 DC Barrier Gate is not only a vehicle access control product but also a complete entrance management component designed for long-term practical use. It combines a DC brushless motor, dual-spring balance system, multiple boom arm options and smart control interfaces to meet the needs of different parking and access control projects.

With flexible speed options, stable performance and professional design, the A9 barrier gate is suitable for both standard parking entrances and customized access control solutions. Whether used in residential communities, commercial parking lots, industrial parks or logistics entrances, it provides a reliable and efficient way to manage vehicle traffic.
